LAPP Mobility Portable Charger Dock

The Mobility Dock is a portable charging station that connects the Type 2 cable you already own to an ordinary household socket. It suits anyone charging an electric or plug-in hybrid car at home, at work or away, without relying on a fixed wallbox. It also works as an adapter, so you don't need to carry a second cable.

Why this charger

• Portable 2.3 kW wallbox — charges at 10 A on 230 V single-phase, in Mode 2 under IEC 61851, with automatic power adjustment.
• Uses the cable you already have — Type 2 socket on the dock and a type E/F power plug for the household outlet.
• Residual current detection — AC 30 mA and DC 6 mA, on top of protection against overcurrent and voltage spikes.
• Temperature watched at two points — sensors in the power plug and inside the dock itself, with a self-test at startup.
• Foldable torque support — it rests the unit's 0.7 kg against the wall, and the angled design directs cable traction downwards instead of pulling on the earth contact.
• LED indicator — you follow the status while the dock monitors charge level, temperature and position, with AC and DC fault detection.

Specifications

• Connectors: Type 2 socket and type E/F power plug
• Charging mode: Mode 2 (IEC 61851)
• Nominal current: 10 A
• Nominal voltage: 230 V, single-phase
• Maximum power: 2.3 kW, automatically adjusted
• Residual current detection: AC 30 mA / DC 6 mA
• Protection rating: IP44
• Operating temperature: -25 °C to +45 °C
• Dimensions: 255 × 135 × 105 mm
• Weight: 0.7 kg
• Status display: LED indicator
• Materials: halogen-free, flame- and oil-resistant

What's in the box

• Mobility Dock with type E/F power plug
• Charging cable not included

Compatibility

It works with any electric or plug-in hybrid car that charges over a Type 2 cable: you plug that cable into the dock's Type 2 socket. On the mains side you need a household type E/F socket on 230 V single-phase. The charging cable is not included.
