Wallbox Morek EV – 7.4 kW / 22 kW – LAN/Wi-Fi & Premium 4G

The Morek EV wallbox comes in 7.4 kW single-phase and 22 kW three-phase, both at 32 A. It suits a home, a business or a shared car park: you choose a Type 2 socket or an integrated cable, and LAN/Wi-Fi or Premium connectivity with 4G, MID meter and Mobi.E. It has a 3.8" LCD screen and RFID authentication.

Why this wallbox

• Two power levels — 7.4 kW at 32 A single-phase, or 22 kW at 32 A three-phase.
• Charging starts without an app — Plug & Charge, with RFID card authentication when you want to control who uses the charger.
• Information on the unit — 3.8" LCD screen showing charging status and consumption in real time.
• Premium version for remote management — LAN, Wi-Fi and 4G, with a certified MID meter and Mobi.E network compatibility.
• Electrical protection — residual current detection at AC 30 mA and DC 6 mA, overcurrent and overvoltage protection, CE and TÜV certified.
• Indoors or outdoors — IP55 and IK08, mounted on a wall or on a pole.

Specifications

• Maximum power: 32 A / 7.4 kW or 32 A / 22 kW, depending on the version
• Phases: single-phase or three-phase, depending on the version
• Supply: 220 V or 400 V, 50/60 Hz, depending on the version
• Dimensions: 455 × 260 × 150 mm
• Weight: 4.6 kg
• Vehicle connection: Type 2, socket or integrated cable
• Screen: 3.8" LCD
• Connectivity: Wi-Fi, Bluetooth, Ethernet and 4G, depending on the version
• Residual current detection: AC 30 mA / DC 6 mA
• Protection rating: IP55 / IK08
• Certifications: CE, TÜV
• Authentication: RFID on every version

What's in the box

• Morek EV wallbox
• Integrated Type 2 cable, on the cable variants
• MID meter, on the Premium variants with 4G and Mobi.E
• The Dynamic Load Management (DLM) module is not included and is bought separately

Compatibility

It charges electric and plug-in hybrid vehicles with a Type 2 inlet. The 7.4 kW version connects to a single-phase 220 V installation and the 22 kW version to a three-phase 400 V one, so your choice depends on your electrical supply. The power your car receives also depends on its onboard charger. The Premium variants with 4G are compatible with the Mobi.E network; the LAN/Wi-Fi variants are not. DLM lets you share the available power across several chargers on the same installation.
